Multi Colour Cut Pile Machine Tufting Machine
This Multi Color Cut Pile Tufting Machine adopts individual needle control system as well as servo sliding needle bar system. It can pick up any color at any point as per design when running tufting, therefore not any loop or cut pile burying required on multi color design, no yarn waste on pile. It can be widely used to produce door mats, bathmats, carpet tiles and hand-made carpet in carpet industry and overtufting on carpets&embroidery on textile fabrics in textile industry.
- Description
| Specification | Details |
|---|---|
| Machine Size – 2m Model | L × W × H: 6.4m × 1.5m × 2.7m |
| Machine Size – 4m Model | L × W × H: 8.3m × 1.5m × 2.7m |
| Working Width | 2m or 4m |
| Gauge | 3/16" or 5/32" |
| Pile Height | 10–25 mm |
| Mechanical Speed | Maximum 400 RPM |
| Stitch Rate | 25–50 stitches / 10 cm |
| Yarn | 1200–3000D twisted yarn or cotton yarn |
| Total Power – 2m | 35 kW |
| Total Power – 4m | 45 kW |
