Carpet Machinery · Multi Needle Tufting Machine
6+6 Tufting Machine
1/6‘‘ and 1/6‘‘ multi-loop computerized tufting machine, which calls 6+6. This loop tufting machine allows you to make large flowing patterns with timeless patterns. It is widely used to produce wall to wall carpet tiles for contract and commercial market.
- Description
| Specification | Details |
|---|---|
| Machine Size – 2m | L × W × H: 6.6m × 2.2m × 3m |
| Machine Size – 4m | L × W × H: 8.6m × 2.2m × 3m |
| Working Width | 2m or 4m |
| Machine Gauge | 1/12", 1/6" + 1/6" front and rear two needle bars |
| Pile Height | 2.5–9 mm |
| Mechanical Speed | 1000 RPM |
| Stitch Rate | 25–60 stitches / 10 cm |
| Total Power – 2m | 40 kW |
| Total Power – 4m | 55 kW |
| Needle Bar System | Double sliding needle bar with cam |
| Yarn Feeding | Customized yarn feeding servo motor |
| Yarn Feeding Control | Independent control yarn feeding |
| Primary Back Feeding | Servo motor + planetary reducer |
| Puller Roller | Servo motor controlled |
| Pattern Control | Pattern control software |
| Operation | Touch-screen operation and settings |
